แอมป์ CLASS D คุณภาพสูง HELIX D ONE (เสียงดี)

• Small footprint Class D amplifier with high output power of 600 Watts RMS @ 1 Ohm for easiest combination with all 2 x 2 Ohms subwoofers connected in parallel
• Start-Stop capability down to 6V supply voltage
• Smart highlevel input with ADEP circuit (Advanced Diagnostics Error Protection) and Auto Turn-On function
• Integrated, active crossover with lowpass, bass boost, subsonic and phase control
• Extremely stable output stage with high-current power transistors and 1 Ohm stability
• Bass remote control for volume adjustment
• SMD (Surface Mounted Device) manufacturing technology combines minimum space requirement with maximum reliability
• Exclusive, extremely compact and clean design with illuminated HELIX-logo and low heat dissipation thanks to extraordinary efficiency

Special features:

Smart highlevel input

The latest generation of OE car radios incorporates sophisticated possibilities of diagnosing the connected speakers. If a common amplifier will be hooked up failure messages and loss of specific features (e.g. fader function) quite often appear - but not with the M ONE.
The new ADEP circuit (Advanced Diagnostics Error Protection) avoids all these problems without loading the speaker outputs of the OE radio during high volumes unnecessarily.

Start-Stop capability

The switched power supply of the HELIX M ONE assures operation even if the battery’s voltage drops down to 6 Volts during engine crank.

Technical data:

• RMS data
• 1 x 200 watts @ 4 ohms
• 1 x 340 watts @ 2 ohms
• 1 x 530 watts @ 1 ohm on mono bridged
• Maximum specifications:
• 1 x 400 watts @ 4 ohms
• 1 x 680 watts @ 2 ohms
• 1 x 1060 watts @ 1 ohm on mono bridged
• Amplifier technology: Class D
• Inputs :
• 2 x RCA
• 2 x High Level Speaker Input
• 1 x Remote In
• 1 x Remote Control Input
• Outputs :
• 1 x Speaker Output
• Frequency range: 10 Hz - 250 Hz
• Bass boost: 0 - 12 db / 45 Hz
• Low pass: 50 - 250 Hz adjustable
• Bandpass: 10 Hz - 250 Hz adjustable
• Subsonic: 10 - 50 Hz adjustable
• Phase: 0 - 180° adjustable
• Noise factor: <0.05%
• Signal/noise ratio: > 95 dB (A-rated)
• Attenuation factor: > 200
• Input sensitivity:
• High level: 1 - 14 V
• RCA: 0.5 - 6 volts
• Input impedance Chinch: 30 kOhm.
• Input impedance high level: 12 ohms.
• Operating voltage: 9.6 - 16 V
• Fuse: 2 x 30A Maxi Fuse (FK3)
• Additional features: active, adjustable crossover, bass boost, phase shift, master/slave mode switch, high-level input with automatic switching on and advanced diagnostics error protection (ADEP), bass level cable remote control.
• Dimensions:
• Height: 5.3 cm
• Width: 25 cm
• Depth: 23 cm
